P76E facade element system

Easy-to-install element system for facade construction.

• Highly insulated aluminium element facade system, Ucw-value down to 0,49 W/m2
  K (1500×3300).
• Appearance according to the facade system from the inside and outside, without visible sealing groove.
• Powder coated or anodized surface treatment. Different finishes of inside and outside possible.
• New profile shapes can be produced easy and quickly from our experienced design and production teams.
• Minimal care and maintanance required.
• Completely recyclable.
• High resistance to Nordic weather conditions
• Air permeability AE 1200 (EN 12152)
• Water tightness RE 1050 (EN 12154)
• Frame width 76mm
• Standard frame depth 170 mm.
• Glass thickness from 56 mm up to 59 mm.
• P76E-system will always be tailored to the project.
• Element mounting
• Panels
